Low operating cost:Compared with conventional mechanical agitation flotation machines,it can save 1/3-1/2 of electricity. High sorting accuracy and low ash content of clean coal:The ash content of clean coal can be reduced by 1~2%compared with conventional mechanical stirring flotation machines. Good flotation effect:It is equipped with automatic liquid level control and electronic control device,and the foam is highly refined,thus improving the flotation effect. The wearing parts are highly durable:the impeller is always active in the machine,which plays a role in removing accumulated materials and debris,reducing the damage to components due to debris;and the impeller of the mixing device is made of ground rubber. Enhanced wear resistance.
In the flotation machine, the slurry after the addition of the chemical treatment is stirred and aerated, so that some of the ore particles are selectively fixed on the bubbles and the surface of the slurry is scraped to form a foam product, with the other part left in the slurry, which achieves the purpose of separating minerals.
We will deliver products timely by contract.We will supply you with installation drawings,specifications and operation manual.We offer lifetime warranty and components for products.
| Model | Trough volume （m³） |
Inside dimensions （L×W×H） （m） |
Air suction amount （m³·min） |
Power （kw） |
Motor model | Processing capacity （m³/min） |
| BF-0.37 | 0.37 | 0.74×0.74×0.75 | 0.9～1.05 | 1.5 | Y90L-4 | 0.2～0.4 |
| BF-0.65 | 0.65 | 0.85×0.95×0.9 | 0.9～1.10 | 3.0 | Y132S-6 | 0.3～0.7 |
| BF-1.2 | 1.2 | 1.05×1.15×1.10 | 1.0～1.10 | 5.5 4.0 |
Y132M2-6 Y132M1-6 |
0.6～1.2 |
| BF-2.0 | 2.0 | 1.40×1.45×1.12 | 1.0～1.10 | 7.5 | Y160M-6 | 1.0～2.0 |
| BF-2.8 | 2.8 | 1.65×1.65×1.15 | 0.9～1.10 | 11 | Y180L-8 | 1.4～3.0 |
| BF-4.0 | 4.0 | 1.9×2.0×1.2 | 0.9～1.10 | 15 | Y200L-8 | 2～4 |
| BF-6.0 | 6.0 | 2.2×2.35×1.3 | 0.9～1.10 | 18.5 | Y225S-8 | 3～6 |
| BF-8.0 | 8.0 | 2.25×2.85×1.4 | 0.9～1.10 | 22 30 |
Y225M-8 Y250M-8 |
4～8 |
| BF-10 | 10 | 2.25×2.85×1.7 | 0.9～1.10 | 22 30 |
Y225M-8 Y250M-8 |
5～10 |
| BF-16 | 16 | 2.85×3.8×1.7 | 0.9～1.10 | 37 45 |
Y280S-8 Y280M-8 |
8～16 |
| BF-20 | 20 | 2.85×3.8×2.0 | 0.9～1.10 | 37 45 |
Y280S-8 Y280M-8 |
10～20 |
| BF-24 | 24 | 3.15×4.15×2.0 | 0.9～1.10 | 45 | Y280M-8 | 12～24 |
| Model | Trough volume （m³） |
Processing capacity （m³/min） |
| BF-0.37 | 0.37 | 0.2～0.4 |
| BF-0.65 | 0.65 | 0.3～0.7 |
| BF-1.2 | 1.2 | 0.6～1.2 |
| BF-2.0 | 2.0 | 1.0～2.0 |
| BF-2.8 | 2.8 | 1.4～3.0 |
| BF-4.0 | 4.0 | 2～4 |
| BF-6.0 | 6.0 | 3～6 |
| BF-8.0 | 8.0 | 4～8 |
| BF-10 | 10 | 5～10 |
| BF-16 | 16 | 8～16 |
| BF-20 | 20 | 10～20 |
| BF-24 | 24 | 12～24 |
