MBS Type Rod Mill

Rolling bearings are used instead of traditional sliding bearings to improve starting conditions, reduce the starting torque of the mill and the current during normal operation. The energy consumption of the mill during normal operation is 15 to 20% lower than that of a mill using traditional bearing bushes;

Flexible design of the discharge department, the feeding part has a large amount of feed;

The discharge port can be selected as either grid type or overflow type according to process requirements;

The feed inlet is equipped with a feeding spiral to force feeding, which increases the feeding amount;

Liner castings: The structure, shape and material of the cylinder lining plate, end lining plate, compartment plate and discharge grate plate have been tested by long-term production practice;

Use a closed system to reduce dust:The ultra-fine ball mill and classifier form a closed system, with negative pressure transportation and small dust, reducing harm to the human body.
