Applied materials: various rocks, ores, granite, basalt, limestone, marble, river pebbles, cobbles, bluestone, gangue, dolomite, calcite, quartzite, etc.
The crusher can handle materials of various hardnesses, including but not limited to various rocks, ores, granite, basalt, limestone, marble, river pebbles, cobbles, bluestone, gangue, dolomite, calcite, quartzite, etc.
The material is fed by a feeder, wheel loader or conveyor. The feeder lifts the material to the double-layer screen, which then separates the material to the oversize and side conveyors. With the bidirectional split option, the top and bottom layers of material can be combined to the oversize conveyor (removing fines).
We will deliver products timely by contract.We will supply you with installation drawings,specifications and operation manual.We offer lifetime warranty and components for products.
| Series | Standard Model | On board Equipment | On board Equipment | Processing Capability(t/h) | Transport Dimensions(mm) |
| MOBILE COARSE CRUSHING STATION |
MTF96 | GZDT9538 | CJ96 | 70-200 | 13000×2950×4250 |
| MTF98 | GZDT9538 | HDX98 | 80-200 | 13000×2950×4250 | |
| MTF106 | GZDT1145A | CJ106 | 90-300 | 14000×3000×4400 | |
| MTF110 | GZDT1145A | HDX110 | 120-300 | 14000×3000×4400 | |
| MTF1213C | GZDT9538 | Cl1213 | 80-200 | 13000×2950×4250 | |
| MTF1316C | GZDT1145A | Cl1316 | 100-300 | 14000×3000×4400 | |
| MOBILE MEDIUM AND FINE CRUSHING STATION |
MTF300 | 一 | HPM300C1 | 100-200 | 15500×2900×4200 |
| MTF400 | 一 | HPM400C3 | 150-300 | 16500×3100×4300 | |
| MTF250 | 一 | SC250F1 | 90-200 | 16500×3100×4300 | |
| MTF1213 | 一 | Cl1213 | 80-200 | 16000×2900×4300 | |
| MTF1316 | 一 | Cl1316 | 100-300 | 16500×3100×4500 | |
| MTF0926 | 一 | HV10926 | 85-200 | 16500×3100×4300 | |
| MTF1040 | 一 | HV11040 | 120-300 | 16500×3100×4400 | |
| MOBILE SCREENING STATION | MTF1865-3 | 一 | 3HX1865 | 65-200 | 14500×2900×4000 |
| MTF2165-3 | 一 | 3HX2165 | 85-300 | 15000×2900×4400 | |
| MOBILE STATION FOR MEDIUM AND FINE CRUSHING AND SCREENING |
MTF300S-3SⅡ | 3HX1865 | HPM300C1 | 100-200 | 15000×3000×4000 |
| MTF300S-3 | 3HX2165 | HPM300C1 | 100-200 | 15000×3000×4000 | |
| MTF400S-3 | 3HX2165 | HPM400C3 | 150-300 | 15000×3000×4000 | |
| MTFG400S-3SⅡ | 3HX1865 | GYS400C1 | 100-200 | 15000×3000×4000 | |
| MTFG400S-3 | 3HX2165 | GYS400C1 | 100-200 | 15000×3000×4000 | |
| MTF250S-3 | 3HX2165 | SC250F1 | 90-200 | 15000×3000×4200 | |
| MTF1213S-3 | 3HX1865 | Cl1213 | 80-200 | 15000×3000×4200 | |
| MTF1316S-3 | 3HX2165 | Cl1316 | 100-300 | 15000×3000×4200 | |
| MTF0926S-2 | 2HX1865 | HVI0926 | 85-200 | 18000×3000×4200 | |
| MTF1040S-2 | 2HX2165 | HV11040 | 120-300 | 18000×3000×4200 | |
| THREE COMBINATION MOBILE STATION |
MTF1213-Ⅲ | GZDT9538/3HX1865 | Cl1213 | 80-200 | 18200×2800×4350 |
| MTF1316-Ⅲ | GZDT1145A/3HX2165 | Cl1316 | 100-300 | 18200×3000×4200 | |
| MTF1410-Ⅲ | GZDT9538/3HX1865 | PCZ1410 | 80-200 | 18200×2800×4200 | |
| MTF1612-Ⅲ | GZDT1145A/3HX2165 | PCZ1612 | 100-300 | 18200×3000×4200 | |
| FOUR COMBINATION MOBILE STATION |
MTF100Y-2 | GZD850×3000/2YK1545 | HD72/GYS300 | 50-100 | 15000×2650×4500 |
| MTF100Y-3 | GZDT0835/3HX1548 | HDX86/SC100F1 | 50-100 | 17500×2500×4000 | |
| MTF150Y-3 | GZDT0835/3HX1548 | HDX86/SC160F1 | 70-150 | 17500×2500×4000 | |
| MTF150R-3 | GZDT0835/3HX1548 | HDX86/CI1110 | 60-150 | 17500×2500×4000 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Series | Standard Model | Processing Capacity (t/h) |
| MOBILE COARSE CRUSHING STATION | MTF96 | 70-200 |
| MTF98 | 80-200 | |
| MTF106 | 90-300 | |
| MTF110 | 120-300 | |
| MTF1213C | 80-200 | |
| MTF1316C | 100-300 | |
| MOBILE MEDIUM AND FINE CRUSHING STATION | MTF300 | 100-200 |
| MTF400 | 150-300 | |
| MTF250 | 90-200 | |
| MTF1213 | 80-200 | |
| MTF1316 | 100-300 | |
| MTF0926 | 85-200 | |
| MTF1040 | 120-300 | |
| MOBILE SCREENING STATION | MTF1865-3 | 65-200 |
| MTF2165-3 | 85-300 | |
| MOBILE STATION FOR MEDIUM AND FINE CRUSHING AND SCREENING | MTF300S-3SⅡ | 100-200 |
| MTF300S-3 | 100-200 | |
| MTF400S-3 | 150-300 | |
| MTFG400S-3SⅡ | 100-200 | |
| MTFG400S-3 | 100-200 | |
| MTF250S-3 | 90-200 | |
| MTF1213S-3 | 80-200 | |
| MTF1316S-3 | 100-300 | |
| MTF0926S-2 | 85-200 | |
| MTF1040S-2 | 120-300 | |
| THREE COMBINATION MOBILE STATION | MTF1213-Ⅲ | 80-200 |
| MTF1316-Ⅲ | 100-300 | |
| MTF1410-Ⅲ | 80-200 | |
| MTF1612-Ⅲ | 100-300 | |
| FOUR COMBINATION MOBILE STATION | MTF100Y-2 | 50-100 |
| MTF100Y-3 | 50-100 | |
| MTF150Y-3 | 70-150 | |
| MTF150R-3 | 60-150 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
